CC-GRIND grinding discs SOLID SGP INOX ★★★★

Grinding disc, CC-GRIND®-SOLID, 7" x 7/8, SGP INOX VICTOGRAIN®-COOL, Ceramic

EDP:
61242

Login / Register
Choose options
Dia. external
Mounting system
Technical information
Grinding disc, CC-GRIND®-SOLID, 7" x 7/8, SGP INOX VICTOGRAIN®-COOL, Ceramic

Item number product.detail.hint.sku
64189180
Abrasive
VICTOGRAIN
Dia. external
7 Inch
Dia. external
180 mm
Dia. hole
7/8 Inch
Dia. hole
22.23 mm
EDP no.
61242
Max. RPM
8500 RPM
Mounting system
center hole
Shape
CC-GRIND®-SOLID
Packaging unit
10 pieces
Description

Special Line SGP includes products engineered for specific tasks that offer the user key advantages over conventional products. This quality line also includes products that, due to their particularly high performance, offer ultimate economic efficiency.

With the CC-GRIND®-SOLID, PFERD offers a modern, high-performance and ergonomic alternative to conventional grinding wheels.

Grinding disc with precision-molded, triangular high-performance abrasive VICTOGRAIN® for stainless steel (INOX). Maximum grinding performance and outstanding service life.

VICTOGRAIN® abrasive material is used to make some of the most effective grinding products in the world. PFERD’s triangular, precision-formed grain achieves ultimate performance. The VICTOGRAIN® abrasive grain triangles are identical in shape and size and their cutting edges are applied to the workpiece at the optimum angle, meaning the grain needs very little energy to penetrate the workpiece. As a result, the user experiences superior productivity due to: extremely high stock removal, a long service life, and reduced heat build-up in the workpiece. Each VICTOGRAIN abrasive grain triangle is firmly fixed on one of its sides to the backing material. Due to the slim design, VICTOGRAIN offers an extremely large chip space for maximum cutting efficiency. The structure of the triangular VICTOGRAIN is specially engineered to maximize results. The very fine crystalline structure ensures optimal wear characteristics as sharp cutting edges are always exposed, with the minimum amount of abrasive breaking off from the triangle. By combining all these properties together, users benefit from optimal, consistent performance, cool grinding and an extremely long service life with uniform workpiece surface roughness.

Advantages
  • Ultimate aggressive performance for fast results.
  • Significantly more ergonomic than a conventional grinding wheel: noise and vibrations are reduced by 50%, dust by 80%.
  • Layered structure of the fibreglass backing pad facilitates use that is just as durable and safe as with a grinding wheel.
  • Superior surface finish compared to conventional grinding wheels.
  • Although the VICTOGRAIN® products only come with a single coating of abrasive grit, they offer an outstanding service life which exceeds that of conventional grinding wheels and many flap discs.
Recommendations for use
  • Only use the face of the disc, not suitable for peripheral grinding (on edge).
  • For optimal results, use with a flat contact angle and the SFS CC-GRIND® clamping flange set.
Ordering notes
  • Please order clamping flange set separately.
Workpiece materials
Stainless steel (INOX)
Applications
Chamfering
Deburring
Work on weld seams
Compatible power tools
Angle grinder
PFERDVALUE

PFERDEFFICIENCY

recommends CC-GRIND®-SOLID with VICTOGRAIN abrasive grain for working for long periods with low levels of fatigue, whilst saving resources and achieving perfect results as quickly as possible.
product.aggregation.prv-eff
product.aggregation.prv-eff
product.aggregation.prv-eff
product.aggregation.prv-eff

PFERDERGONOMICS

recommends CC-GRIND®-SOLID with VICTOGRAIN abrasive grain to sustainably reduce the vibration, noise and dust produced during use and to perceptibly improve comfort when working.
product.aggregation.prv-ergo
product.aggregation.prv-ergo
product.aggregation.prv-ergo
product.aggregation.prv-ergo
